TI ICs Interface - Drivers, Receivers, Transceivers 3.3V SN65HVD12DR

 TI ICs Interface - Drivers, Receivers, Transceivers 3.3V SN65HVD12DR







Features
• Operates With a 3.3-V Supply
• Bus-Pin ESD Protection Exceeds 16-kV HBM
• 1/8 Unit-Load Option Available (Up to 256 Nodes on the Bus)
• Optional Driver Output Transition Times for Signaling Rates (1) of 1 Mbps, 10 Mbps, and 32 Mbps
• Meets or Exceeds the Requirements of ANSI TIA/EIA-485-A
• Bus-Pin Short-Circuit Protection From –7 V to 12 V
• Low-Current Standby Mode: 1 µA, Typical
• Open-Circuit, Idle-Bus, and Shorted-Bus Failsafe Receiver
• Thermal Shutdown Protection
• Glitch-Free Power-Up and Power-Down Protection for Hot-Plugging Applications
